Walfront G1/2 DN15 Automatic Electronic Timed 2-Way Drain Valve for Air Compressor Condensate Management 110V, Inlet Valve

How to Use: Timer Setting: Left knob to set the discharge time, the right knob to set the interval time; the first discharge time of 2s, the interval time is 20min, and then need to be further adjusted. Specification: Item Type: Drain Valve Valve Material: Brass Color: As shown in the picture Model: 588158 Voltage: AC110V 50Hz Voltage Range: 10% Time Interval(OFF): 0.5-45 minutes (adjustable) Discharge Time(ON): 0.5-10 seconds (adjustable) Manual Test Button: Yes( micro switch) The Current Consumption: Maximum 4mA Ambient Temperature: -40°C to 60°C. Grade: IP65 Shell Material: Flame retardant ABS plastic Electrical Connection: DIN43650A Indicator Lamp: LED indicating power ON / OFF Type: Two-way direct-acting valve Aperture: 5mm / 0.2in Insulation Class: H In / Out Port Size: 1/2in Maximum Working Pressure: 1.6Mpa Maximum Temperature: 90°C Weight: Approx. 542g / 19.1oz Package List: 1 x Drain Valve 1 x Connector Note: When installing an electronic drain valve, make sure that: 1. Compressed air has been emptied (at zero pressure) 2. Power has been cut off 3. Professional equipment should be installed by professionals.

• Note for use: the compressed air system before installation. Be sure to tighten the long screws on the junction box to prevent the water from scorching. When using, pay attention to the arrow direction of the valve body, and do not use an impact hose for the water outlet to avoid impact.
• Voltage: AC110V 50Hz, the power supply voltage must be the same as the drain valve voltage; when using DC, the pole must be connected to the connector.
• Time setting range: the valve opening time is adjustable from 0.5-10 seconds, and the closing time is 0.5-45 minutes. aperture: 5mm/0.2in.
• Timer setting: the left knob sets the discharge time, the right knob sets the interval time; the first discharge time is 2s, the interval time is 20min, and further adjustments are needed afterwards.
• Item type: This is a reliable, high-quality drain valve that can keep the compressed air handling equipment operating at its best.
